Type de roulement: deux roulements à billes
matériau: turbines et;Cadre: plastique (UL94V - 0)
plomb: ul1007 awg26
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Ligne rouge positive (+)
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Noir négatif一)
poids: 76,0 G
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA08025_12J | B/S/F | 12 | 7.0~13.2 | 0.14 | 2700 | 34.6 | 3.1 | 28 |
| WSA08025_48J | B/S/F | 48 | 28.0~56.0 | 0.05 | 2700 | 34.6 | 3.1 | 28 |
| WSA08025_12L | B/S/F | 12 | 7.0~13.2 | 0.15 | 3000 | 38.5 | 3.9 | 31 |
| WSA08025_24L | B/S/F | 24 | 14.0~26.4 | 0.1 | 3000 | 38.5 | 3.9 | 31 |
| WSA08025_48L | B/S/F | 48 | 28.0~56.0 | 0.07 | 3000 | 38.5 | 3.9 | 31 |
| WSA08025_12M, | B/S/F | 12 | 7.0~13.2 | 0.23 | 3600 | 46.1 | 5.4 | 36 |
| WSA08025_24M | B/S/F | 24 | 14.0~26.4 | 0.16 | 3600 | 46.1 | 5.4 | 36 |
| WSA08025_48M | B/S/F | 48 | 28.0~56.0 | 0.07 | 3600 | 46.1 | 5.4 | 36 |
| WSA08025_12H | B/S/F | 12 | 7.0~13.2 | 0.32 | 4300 | 55 | 7.4 | 40 |
| WSA08025_24H | B/S/F | 24 | 14.0~26.4 | 0.23 | 4300 | 55 | 7.4 | 40 |
| WSA08025_48H | B/S/F | 48 | 28.0~56.0 | 0.11 | 4300 | 55 | 7.4 | 40 |
| WSA08025_12U | B/S/F | 12 | 7.0~13.2 | 0.52 | 5000 | 76 | 14.5 | 44 |
| WSA08025_24U | B/S/F | 24 | 14.0~26.4 | 0.4 | 5000 | 76 | 14.5 | 44 |
