Type de roulement: deux roulements à billes
matériau: turbines et;Cadre: plastique (UL94V - 0)
plomb: ul1007 awg26
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Ligne rouge positive (+)
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Noir négatif一)
poids: 18,0 G
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum Air Pressure | Noise |
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA07010_05L | B/S | 5 | 3.5~5.5 | 0.15 | 1500 | 6.6 | 11.1 | 25 |
| WSA07010_05M | B/S | 5 | 3.5~5.5 | 0.35 | 2500 | 10.4 | 18.5 | 27.2 |
| WSA07010_05H | B/S | 5 | 3.5~5.5 | 0.5 | 3000 | 12.4 | 22.5 | 32.8 |
| WSA07010_12L | B/S | 12 | 7.0~13.2 | 0.12 | 1500 | 6.6 | 11.1 | 25 |
| WSA07010_12M | B/S | 12 | 7.0~13.2 | 0.25 | 2500 | 10.4 | 18.5 | 27.2 |
| WSA07010_12H | B/S | 12 | 7.0~13.2 | 0.4 | 3000 | 12.4 | 22.5 | 32.8 |
| WSA07010_24L | B/S | 24 | 14.0~26.4 | 0. 08 | 1500 | 6.6 | 11.1 | 25 |
| WSA07010_24M | B/S | 24 | 14.0~26.4 | 0.15 | 2500 | 10.4 | 18.5 | 27.2 |
| WSA07010_24H | B/S | 24 | 14.0~26.4 | 0.25 | 3000 | 12.4 | 22.5 | 32.8 |
