Type de roulement: deux roulements à billes
matériau: turbines et;Cadre: plastique (UL94V - 0)
plomb: ul1007 awg26
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Ligne rouge positive (+)
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Noir négatif一)
poids: 40,g
| MODEL | Bearing System | Rated Voltage | Operating Voltage Range | Input Current | Speed | Maximum Air Flow | Maximum | Noise |
| Air Pressure | ||||||||
| PART NO | B/S/F | VDE | VDE | AMP | RPM | CFM | MmH2O | Db-A |
| WSA04028_12L | B/S/F | 12 | 7.0~13.2 | 0.18 | 8000 | 13.9 | 0.46 | 40 |
| WSA04028_12M | B/S/F | 12 | 7.0~13.2 | 0.26 | 9500 | 15.9 | 0.69 | 42 |
| WSA04028_24M | B/S/F | 24 | 14.0~24.6 | 0.15 | 9500 | 15.9 | 0.69 | 42.5 |
| WSA04028_12H | B/S/F | 12 | 7.0~13.2 | 0.35 | 11000 | 18.7 | 0.92 | 48 |
| WSA04028_24H | B/S/F | 24 | 14.0~24.6 | 0.2 | 11000 | 18.7 | 0.92 | 48 |
| WSA04028_12U | B/S/F | 12 | 7.0~13.2 | 0.55 | 13000 | 23.8 | 1.32 | 54 |
| WSA04028_24U | B/S/F | 24 | 14.0~24.6 | 0.27 | 13000 | 23.8 | 1.32 | 54 |
| WSA04028_12V | B/S/F | 12 | 7.0~13.2 | 0.7 | 15000 | 24.8 | 1.64 | 58 |
